Surgical Guide Resin
Surgical Guide Resin
Download Technical Data Sheet
Pionext Surgical Guide Resin (PN-SG) is a medical-grade, highly transparent photopolymer resin engineered specifically for the fabrication of custom surgical guides and implant placement templates. Formulated to offer a combination of high flexural strength, superior optical clarity, and low-yellowing performance, this resin empowers clinicians to execute guided surgery with absolute precision and safety.
Validated Printers: Piocreat DJ-68, Piocreat DJ-89Plus, Piocreat D158
In stock
Couldn't load pickup availability
Product Description
Product Description
Pionext Surgical Guide Resin (PN-SG)
High-Transparency Resin for Dental 3D Printing
Pionext Surgical Guide Resin (PN-SG) is a UV-curable resin designed for dental 3D printing applications. It combines high transparency, flexibility, and low shrinkage, making it suitable for the production of dental implant surgical guides and related applications.
Key Features & Benefits
High Transparency
Designed with high transparency to provide clear visibility of printed models and fine details.
High Flexibility
Offers a combination of flexibility and mechanical strength for demanding dental 3D printing applications.
Low Shrinkage
Formulated with low shrinkage to support consistent printing results and detailed model production.
Suitable for Dental Applications
The resin is designed for dental 3D printing and is suitable for dental implant surgical guides and related applications.
Material Properties
- Shore D Hardness: 75–85
- Flexural Modulus: 2,500–3,500 MPa
- Flexural Strength: 100–120 MPa
- Tensile Modulus: 2,500–3,000 MPa
- Tensile Strength: 50–70 MPa
- Elongation at Break: 20–30%
- Notched Izod Impact Strength: 30–50 J/m
- Heat Deflection Temperature: 60–70°C
Recommended Printing Parameters
The manufacturer provides recommended printing parameters for compatible Piocreat printers, including the DJ-68, DJ-89Plus, and D158. Refer to the Technical Data Sheet for detailed settings.
Post-Processing
After printing:
- Clean the printed model with absolute ethanol or isopropanol. A low-frequency ultrasonic cleaner may be used.
- Thoroughly dry the model to remove residual cleaning liquid.
- Remove most supports before post-curing.
- For applications requiring additional toughness, the TDS states that the printed part may be UV post-cured for 5 minutes. Final curing time should be adjusted according to the selected curing method.
Storage & Use
- Storage Temperature: Below 25°C
- Storage: Protect from visible light
- Shelf Life: 18 months
- Before Use: Shake thoroughly
- Recommended Printing Temperature: 18–35°C
Safety Information
For safe handling, refer to the manufacturer's current SDS/MSDS and applicable regulatory documentation. Avoid direct eye and skin contact with the resin and follow appropriate handling procedures.
